Introduction of copper cable separation machine:
Copper cable separetion machine is a professional dry separation of waste wire and cable production line will be separated into tiny copper rice and plastic,the applicable range of waste wire diameter of 0.3 mm to 20 mm, the old auto circuit lines ,communication cables and wire stripping machine is not suitable formachining (various civilian wire).Waste miscellaneous material wire, filament wire can be also broken separation without classification. After crushing processing and shock treatment, screen separation copper and plastic will be sorting out.
Copper cable separation machine
Advantages of copper cable separation machine:
copper cable separation machine
1.Suitable structure and layout, easy to install.
2. PLC system makes it easier to control the whole line, convenient to feed and operate.
3. The design of separator and dust collector is handy for movement or transport.
4. The rotor of the grinder is alternating, leading to more efficiency, faster discharging, low noise and steadier running.
5. Feedback system will do the second crushing to the unfinished material, which guarantees the total separation of metal and non-metal.
6. The separation rate of air separator can reach at least 99%.
7. Dust collector can prevent the leak of dust. The dust cleaning rate can reach 99.99%.
2.Working Principle of copper cable separation machine:
The copper wire is directly put into the copper cable separation machine, it is cut into granules first. During this process, copper and plastic is mixed together. Then the granules are sent to vibration device for separation. Through wind blow and vibration, the copper and plasticis are separated. Finally pure copper comes out from one side and pure plastic comes out from the anther side.
Working process of copper cable separation machine
4.Display of the copper cable separation machine:
Final products of copper cable separation machine
5.Technical parameter of the copper cable separation machine:
|
Model |
Voltage |
Power |
Capacity |
Dimension |
Weight |
|
DYTM-400 |
380V |
22.45 kw |
150-200kg/H |
2700*1900*2300(mm) |
1200kg |
|
DYTM-600 |
380V |
36 kw |
300-400kg/H |
3500*1900*2700(mm) |
3000kg |
|
DYTM-800 |
380V |
75 kw |
500-600kg/H |
5500*4500*3300(mm) |
8000k |
