Copper wire granulator price ?

Date:2017-10-19 16:17:33/ FAQ / Chat Online/ Leave message

Copper wire granulator machine

Our copper wire granulator is mainly used for recycling various scrap communication wire/cable, such as copper wire, aluminum wire, telephone wire, USB wire, computer wire, waste automobile wire and other miscellaneous wires, etc with diameter between 0.1-80mm. The copper and plastic separation rate could reach to 99%. It can process cable and wire which single core, double core or multi-core, either twisted or tangled, with or without plug. Copper wire granulator is mainly composed of the crushing system, air separation system and dust collection system. Its main work theory is to sort and collect the copper via gravity separation, which is dry type processing way without any water, adopts environmental protection way to recycle the scrap copper wire.

Technical parameter:

Copper wire granulator machine

项目Item	型号 Model	处理量 Capacity(kg/h)	功率Power (Kw)	尺寸Size (m) (LWH)	重量 Weight (T)
1	DY-C-100	100-150	27.5	2.902.353.50	2.0
2	DY-C-300	200-300	60.2	4.952.353.50	2.2
3	DY-C-500	300-500	67.0	7.352.354.10	4.2
4	DY-C-800	600-800	80.5	8.852.354.10	4.5
5	DY-C-1000	800-1000	82.0	10.853.804.10	5.5
